Introducing the Deepam Advanced Commercial Stove Series – powered by advanced thermal engineering technology designed to solve today’s cooking industry challenges.
Flexible fuel options reduce operational costs and dependency on LPG
1 Kg/ 3000 kcal of firewood burns for about 20–60 minutes
0.75 kg / 3000 kcal burns for about 45–70 minutes
1 kg / 3000 kcal burns for about 15–30minutes
0.43 kg / 3000 kcal burns for about 60–90 minutes
0.6 kg / 3000 kcal burns for about 90–120 minutes
Customized solutions are available for all commercial cooking requirements.
| SL NO | CAPACITY | OVERALL DIMENSIONS |
COOKING VESSEL SIZE |
MATERIAL | FUEL TYPE | FLAME CONTROL | BLOWER | WOOD TRAY |
ASH TRAY |
NOZZLE | FINISH | INNER INSULATION | OUTER INSULATION | WEIGHT |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1 |
5–15 kg | 720 × 720 × 500 mm | 1 ft – 1½ ft | Mild Steel | Biomass & Wood | Adjustable Flame Control | 12V DC Blower | ✓ | ✓ | Multiple Nozzle System | Powder Coated | Ceramic Clay Grade K (Alumina-Silica) |
Ceramic Fiber Blanket 128 Density |
136 KG |
2 |
15–30 kg | 780 × 780 × 520 mm | 1 ft – 1¾ ft | Mild Steel | Biomass & Wood | Adjustable Flame Control | 12V DC Blower | ✓ | ✓ | Multiple Nozzle System | Powder Coated | Ceramic Clay Grade K (Alumina-Silica) |
Ceramic Fiber Blanket 128 Density |
195 KG |
3 |
25–35 kg | 800 × 800 × 520 mm | 1 ft – 2 ft | Mild Steel | Biomass & Wood | Adjustable Flame Control | 12V DC Blower | ✓ | ✓ | Multiple Nozzle System | Powder Coated | Ceramic Clay Grade K (Alumina-Silica) |
Ceramic Fiber Blanket 128 Density |
230 KG |
4 |
50 kg | 1100 × 1100 × 770 mm | 1½ ft – 3 ft | Mild Steel | Biomass & Wood | Adjustable Flame Control | 12V DC Blower | ✓ | ✓ | Multiple Nozzle System | Powder Coated | Ceramic Clay Grade K (Alumina-Silica) |
Ceramic Fiber Blanket 128 Density |
320 KG |
5 |
80 kg | 1600 × 1600 × 920 mm | 2 ft – 3½ ft | Mild Steel | Biomass & Wood | Adjustable Flame Control | 12V DC Blower | ✓ | ✓ | Multiple Nozzle System | Powder Coated | Ceramic Clay Grade K (Alumina-Silica) |
Ceramic Fiber Blanket 128 Density |
550 KG |
6 |
100 kg | 1850 × 1850 × 920 mm | 2¾ ft – 4 ft | Mild Steel | Biomass & Wood | Adjustable Flame Control | 12V DC Blower | ✓ | ✓ | Multiple Nozzle System | Powder Coated | Ceramic Clay Grade K (Alumina-Silica) |
Ceramic Fiber Blanket 128 Density |
850 KG |
| Capacity | Stove Weight |
|---|---|
| 20 KG Capacity Stove | 128 KG |
Premium commercial stove with advanced thermal engineering technology.
In many indoor kitchens, workers spend 8–12 hours in high-temperature environments. To solve this, we have designed an advanced outer insulation system that minimizes heat leakage. This creates a cooler and more comfortable working atmosphere.
Traditional turbo stoves often create excess smoke, causing discomfort in kitchens. Our Free Flow Exhaust System efficiently removes smoke from the cooking area, ensuring a cleaner and healthier environment.
Ash dust is a common issue in conventional stoves and can contaminate food and create an uncomfortable workplace. Our specially engineered nozzle design maintains the correct airflow and combustion ratio to prevent ash spread while maintaining a powerful flame.
The stove uses advanced thermal engineering technology, optimized nozzles, and an efficient blower system to maximize combustion efficiency and convert fuel energy into usable heat, resulting in significantly faster cooking.
The specially designed 20–24 nozzle system ensures equal airflow distribution, providing uniform oxygen supply and even heat distribution around the vessel for consistent cooking results.
The stove features ceramic clay aluminum silica insulation, which minimizes heat loss and improves burning efficiency. This enhances overall stove efficiency by 40–50%.
The blower system with adaptor allows users to increase or decrease airflow according to cooking requirements, enabling high flame and low flame control.
Up to 96% of generated heat is effectively transferred to the cooking vessel through specially designed angled nozzles.
The exhaust system ensures smoke and heat are removed efficiently while maintaining proper oxygen circulation, creating a smoke-free cooking area.
The inner insulation system is designed to maintain structural integrity and thermal performance over time, with an expected lifespan of 5–10 years.
Approximately 2–10% heat from exhaust can be recovered and reused for applications such as hot water generation, minimizing energy wastage.
The stove uses 128-density ceramic insulation, ensuring heat is directed only toward the vessel while preventing heat exposure to workers.
The stove supports continuous operation, continuous fuel feeding, and ash removal without stopping the cooking process.
Compatible with multiple fuel types: Firewood,Hardwood , Coconut Shell , Wood Chips ,Charcoal
Manufactured using heavy-gauge industrial steel and boiler-grade materials for maximum strength and long-lasting performance.
Inside: Black powder coating
Outside: Silver coating
This enhances durability and extends material life.
